OPTICS • 2-element 14:1 zoom • Beam aperture: 4.0° to 56° • 7 x 70 mm truncated frontal lens • 170 mm front lens cluster LIGHT SOURCE • 7 x 1,000 lumens RGBW LED source • Luminaire output: up to 5,200 lumens • CRI: up to 86 • Rated life (L70): up to 40,000 hours • Flicker-free source MOVEMENT • Extremely accurate positioning • Resolution: 8- or 16-bit • Smooth movements • Pan and tilt with automatic repositioning • Range: infinite pan & tilt rotation COLOURS • Sophisticated 4 colours RGBW mixed • 4.29 bilion colours (8-bit resolution) • Virtual colour wheel • Dynamic colour macro effect EFFECTS • 2D & 3D graphical effects capabilities • Built-in pattern effects • Pixel control • LiquidEffectTM DIMMER / STROBE • Electronic dimmer from 0 to 100% • Strobe effect: 1 to 25 flashes per second HARDWARE FEATURES • Graphic LCD display with flip function • Clicking jog wheel to set functions • Integrated LumenRadio™ receiver • XLR 5 pin connectors • etherCON RJ45 connectors • powerCON TRUE1 connector CONTROL • DMX 512 protocol • DMX-RDM compatible • Stand-alone mode, local control panel • ArtNet™ & sACN protocol • 3 DMX modes (26 to 79 DMX channels) POWER SUPPLY • 120 to 240 Volts – 50/60 Hz • Power: 350 W maximum COOLING SYSTEM • Advanced cooling system • Self-adjusting variable speed fans • Selectable ventilation modes • Excess-temperature protection HOUSING • Skeleton in aluminium and steel plates • Base in die-cast aluminium • Moulded covers in ABS PC (V0 class) • Two-side handles • Four heavy-duty feet • IP20 protection rating • Exterior finish: black (Carbon) INSTALLATION • Two Omega ¼ turn brackets • Four ¼ turn mounting points • Safety cable attachment point OPERATING PARAMETERS • Maximum temperature: 45 °C (113 °F) • Minimum temperature: -10 °C (14 °F) • Minimum usage distance: 1.0 m (3.28 ft) COMPLIANCE • EMC Directive 2014/30/EU • LVD Directive 2014/35/EU • US Safety: UL 1573 & FCC Part 15, Subpart B: 2018 SIZE • Product: 365 x 404 x 233 mm (l x h x d) • Foam: 420 x 438 x 280 mm (l x h x d) WEIGHT • Product: 11.1 kg PRODUCT CODE • 013250: ZONDA 3 FX - MULTI-SOURCES 3 SERIES |
